MINTO METALS REPORTS ANOMALIES AND NEW EXPLORATION TARGETS FROM MAGNETOTELLURICS SURVEY

December 20, 2022

Press Releases

WHITEHORSE, YT, Dec. 20, 2022 /CNW/ - Minto Metals Corp. ("Minto" or the "Company") (TSXV: MNTO) is pleased to report results from the 2022 Magnetotellurics survey over the Minto Mine Property.

The Company commissioned Quantec Geoscience Ltd. ("Quantec") to conduct a SPARTAN MT survey, a deep-penetrating Magnetotellurics ("MT") survey over the Minto Mine Property (Figure 1). The goal for the MT survey was to extend the geophysical coverage for the Minto Mine Property to depths below the extents of previous geophysical surveys, diamond drilling and current mining infrastructure to assess the potential for additional economic mineralization. Quantec completed the survey, consisting of a total of 184 SPARTAN MT sites (Figure 2), between July 10, 2022 and August 28, 2022 with results received by the Company in late November 2022.

MT is a passive electromagnetic technique that maps resistivity by measuring telluric currents induced in the earth by natural sources such as lightning, solar flares and ionospheric resonances. SPARTAN MT is full-tensor audio-magnetotelluric technology that acquires data in the 10 kHz to 0.001 Hz frequency band.
For more information on MT and SPARTAN MT refer to: https://quantecgeo.com/spartan-mt/.

Results from the MT survey highlighted three significant low resistivity, moderate to high conductive anomalies on the Minto Mine Property:

A.

A large low resistivity anomaly below the Minto Mine Property orebodies extending to a depth of ~-300m elevation (ELEV) (approximately 650 metres below the lowest current mine development or roughly 1,000 meters below surface (Figures 3&4);

B.

A low-moderate resistivity anomaly to the NE of the Minto Mine Property workings (Figures 3&4) that appears to follow the regional NW-SE structure. The anomaly extends from 200m ELEV to ~-900m ELEV (approximately 1,100 meters of interest); and

C.

A large, low resistivity anomaly at the south end of the Minto Mine Property that likely represents the younger-aged, Little Ridge / Casino Formation mafic volcanics and associated sediments (Figures 3&4).

David Benson, Vice-President Exploration commented, "We are very pleased with the results from the MT survey. The results indicate prospectivity at depth below the current mine levels and validates our initial thinking that the current Minto resource base is limited by the depth of the historical drilling. Equally, we are very excited about drill-testing Anomaly 'B' in 2023 as this has the potential to be a new, mineralized system at Minto. The Company plans to drill test both Anomalies 'A' and 'B' from surface and underground drill platforms in 2023."

Figure 1:  Regional Map of Minto Metals Corp. Projects. All exploration activity reported herein are from the Minto Mine Property and authorized under Quartz Mining Land Use Permit LQ00565. (CNW Group/Minto Metals Corp.)

Figure 1: Regional Map of Minto Metals Corp. Projects. All exploration activity reported herein are from the Minto Mine Property and authorized under Quartz Mining Land Use Permit LQ00565.

Figure 2: Location map for the MT survey over the Minto Mine Property. Individual MT data collection points highlighted. (CNW Group/Minto Metals Corp.)

Figure 2: Location map for the MT survey over the Minto Mine Property. Individual MT data collection points highlighted.

Figure 3: Horizontal MT plan section at 0m ELEV. For comparison, surface infrastructure at the Minto Mine Property is at 790m ELEV; the deepest Minto orebody is currently at 400m ELEV. MT low resistivity anomalies A, B and C denoted. Hatched patterns denote projections of the Minto Mine Property orebodies. Cross-section in Figure 4 denoted by X-X’. (CNW Group/Minto Metals Corp.)

Figure 3: Horizontal MT plan section at 0m ELEV. For comparison, surface infrastructure at the Minto Mine Property is at 790m ELEV; the deepest Minto orebody is currently at 400m ELEV. MT low resistivity anomalies A, B and C denoted. Hatched patterns denote projections of the Minto Mine Property orebodies. Cross-section in Figure 4 denoted by X-X'.

Figure 4:  X-X’cross-section from Figure 3. MT Anomalies A, B and C denoted. Minto orebodies annotated and identified as dark grey shadows.  Interpreted structures denoted by dashed lines. (CNW Group/Minto Metals Corp.)

Figure 4: X-X'cross-section from Figure 3. MT Anomalies A, B and C denoted. Minto orebodies annotated and identified as dark grey shadows. Interpreted structures denoted by dashed lines.

Discussion

The Minto Mine Property orebodies appear within the upper portion and cluster around MT anomaly 'A' that extends to depths up to 650 metres below the current mining infrastructure (Figures 5 & 6). The relationship between mineralized orebodies at the Minto Mine Property and the low resistivity anomaly is not currently constrained due to lack of drilling. Two conceptual targets have emerged based on these results and previous geophysics surveys (Titan DC-IP / MT circa 2010): 1) the entirety of the low resistivity Anomaly 'A'; and 2) the transitional zone between low and moderate resistivity at Anomalies A, B and several other isolated, targets. This data is being integrated into the Minto geological model and will be a key input for ALS Goldspot Discoveries Corp.'s work with machine-learning prospectivity and target generation.

Figure 5.  Plan view map depicting the Minto Mine Property site surface infrastructure (satellite image) and underground mine development (Green) with projected 3D MT resistivity clipped at 100 ohm-m. (CNW Group/Minto Metals Corp.)

Figure 5. Plan view map depicting the Minto Mine Property site surface infrastructure (satellite image) and underground mine development (Green) with projected 3D MT resistivity clipped at 100 ohm-m.

Figure 6.  3D view looking Az 255° (north is to the right) depicting MT Anomaly ‘A’ clipped at 100 ohm-m from Figures 3&4 in spatial relationship to underground mine development from Figure 5. (CNW Group/Minto Metals Corp.)

Figure 6. 3D view looking Az 255° (north is to the right) depicting MT Anomaly 'A' clipped at 100 ohm-m from Figures 3&4 in spatial relationship to underground mine development from Figure 5.

Outlook

The Company has completed its drilling program for 2022 and are awaiting results from 19 drill holes that targeted Minto North and Minto East. Minto expects to report on these results in early January 2023. The Company was recently informed of a January 2023 delivery date for Phase 1 Targeting being conducted by ALS Goldspot Discoveries Corp. that includes machine learning derived prospectivity heat-maps highlighting areas with a high probability for mineralization, prioritized drill targets and an updated 3D geological model. The Company is planning an aggressive resource growth and discovery drill program for 2023 that will include drill-testing the MT anomalies highlighted in this news release and will provide guidance following board of director approval.

Qualified Person

The technical contents of this news release have been reviewed and approved by David Benson, P.Geo. Vice President of Exploration of Minto Metals and Qualified Person as defined by Canadian Securities Administrators National Instrument 43-101 - Standards of Disclosure for Mineral Projects.

About Minto Metals Corp.

Minto operates the producing Minto mine located within the traditional territory of the Selkirk First Nation in the Minto Copper Belt of the Yukon. The Minto mine has been in operation since 2007 with underground mining commencing in 2014. Since 2007, approximately 500Mlbs of copper have been produced from the Minto mine. The current mine operations are based on underground mining, a process plant to produce high-grade copper, gold, and silver concentrate, and all supporting infrastructure associated with a remote location in Yukon. The Minto property is located west of the Yukon River, about 20 km WNW of Minto Landing, the latter on the east side of the river, and approximately 250 road-km north of the City of Whitehorse, the capital city of Yukon.
